DELMHORST FX20 MOISTURE METER

Description

Get accurate hay moisture readings in the field with the Delmhorst FX20 moisture meter. This FX-20/P01 Deluxe Package pairs the FX20 meter with a 10″ prod and H-4 handle, making it ideal for small bales and windrow testing. The prod connects to the handle rather than the meter itself, so everyday use puts stress on the handle, not the meter case or its connections.

Built on the accuracy Delmhorst is known for, the FX20 gives fast, reliable readings so you can time baling with confidence, cut spoilage risk, and protect the quality and value of your hay.

WHAT’S IN THE BOX

• FX-20 Meter
• 324CAS-0112 Carrying Case
• H-4 Handle
• 830-2 10″ Prod
• 831 Short Pin Prod
• QuickStart Guide

KEY FEATURES

• Large, custom display with auto backlight, easy to read in any light or weather
• Modern, ergonomic case with large tactile buttons and an E-Z grip handle
• On-screen statistics for up to 100 saved readings: High, Low, Average and Standard Deviation
• Hay moisture measuring range: 6%-40%
• Alarm set point alerts you when a reading passes your chosen moisture level
• Internal calibration check keeps readings accurate over time
• Audible “Low Batt” warning
• Auto-off timer, adjustable to 1, 4 or 10 minutes, to help save battery life
• Compatible with all Delmhorst electrodes and prods
• QR code on the meter for quick access to support materials and meter registration
• 2-year warranty on manufacturer’s defects, extended further with online registration
• Hard plastic carrying case also available separately for extra protection

TECHNICAL SPECIFICATIONS

Power: 2 x AA alkaline batteries Temperature correction range: 0°F to 255°F (-18°C to 124°C) Meter dimensions: 8.03 x 2.85 x 1.60in (20.40 x 7.24 x 4.06cm) Meter weight: 7.7oz (218g) Manual: FX-20 and FX-30 Owners manual – 05.2024.pdf

FX20 OR FX2000: WHICH ONE DO YOU NEED?

The FX20 is the newer generation of Delmhorst’s long-running FX2000 moisture meter, with an updated display, case design and on-screen statistics, while keeping the same trusted accuracy. If you’d rather stick with the tested and tested original, the FX2000 is still available: FX2000 – Moisture Meter Kit

SPARES AND ACCESSORIES

• Coaxial Prod Probe 10″
• Coaxial Prod Probe 18″
• Coaxial Prod Probe 12″
• Resin Handle with Cable
• Chamber Mounted Sensor Plate
• 40″ Lead Cable, Bale Chamber
• Power Pack

FREQUENTLY ASKED QUESTIONS

Q: What’s included in the Delmhorst FX-20/P01 Deluxe Package for Hay? A: The package includes the FX-20 meter, a 324CAS-0112 carrying case, an H-4 handle, an 830-2 10″ prod, an 831 short pin prod, and a QuickStart guide.

Q: What moisture range does the Delmhorst FX20 measure in hay? A: The Delmhorst FX20 measures hay moisture from 6% to 40%, covering windrow and baled hay testing.

Q: Is the FX20 compatible with older Delmhorst prods and electrodes? A: Yes. The Delmhorst FX20 works with all Delmhorst electrodes and prods, so existing accessories carry over to the new meter.

Q: What’s the difference between the Delmhorst FX20 and the FX2000? A: The FX20 is the newer version of the FX2000, with an updated display, case design and on-screen statistics. The FX2000 remains available for those who prefer the original model.

Q: How long is the warranty on the Delmhorst FX20? A: The Delmhorst FX20 carries a 2-year warranty against manufacturer’s defects, with a bonus warranty period for meters registered online.

Q: What power does the FX20 use? A: The FX20 runs on 2 x AA alkaline batteries, with an audible “Low Batt” warning and an adjustable auto-off timer (1, 4 or 10 minutes) to help conserve power.
